SARS-CoV-2 Spike Protein Overlapping Peptide Array

The SARS-CoV-2 Spike Protein Overlapping Peptide Array is semi-quantitative array displaying 316 synthesized peptides representing the full-length SARS-CoV-2 Spike protein (wild-type). It is suitable for antibody epitope mapping and detection of IgG, IgM, or IgA in serum, plasma, and other liquid sample types.

As low as $598.00
In stock
Only %1 left
Catalog #:
PAH-SMHG-G1
-
+

Product Description

Specifications

Size 1 slide (4 wells), 2 slides (8 wells), 4 slides (16 wells)
Species Human, Mouse, Rabbit
Accession Number P0DTC2
Protein Name / Synonyms Spike protein, S-Protein, Spike glycoprotein
Quantitative/Semi-Quantitative Semi-Quantitative
Number of Targets Detected 316
Compatible Sample Types Plasma, Serum, Ascites, Hybridoma cell culture medium, Other Body, Purified antibodies, Purified protein
Solid Support Glass Slide
Method Of Detection Fluorescence Laser Scanner
Research Area Antibody Drug Development, Drug Antibody (DA) Detection, Receptor-Ligand Binding
Estimated Lead Time 1-2 business days
Shipping Type Blue ice
Storage -20°C
Array Map https://raybiotech.supremeclients.com/files/images/Maps/PAH-SM-G1.png
Amazon Gift Cards!

$5 Amazon gift card in every kit box purchased.

Targets Detected

Number of Peptides Detected
316 Overlapping Peptides (representing the full-length of SARS-CoV-2 spike protein)

Application Notes

  • Vaccine Development: Measure IgG, IgM, or IgA antibody responses to immunization or COVID-19 infection
  • In Vitro Diagnostics Research: Identify immunodominant epitopes within the SARS-CoV-2 spike protein
  • Epitope Profiling: Profile epitope-specific antibody responses against the SARS-CoV-2 spike protein
  • Spike Protein Interaction Studies: Determine the interactions between the SARS-CoV-2 spike protein and other molecules, such as proteins, peptides, and small molecules. (Additional reagents and materials not included in the kit may be required.)

Product Features

  • Small sample volume required
  • High density
  • High sensitivity
  • Large dynamic range
  • Suitable for high-throughput assays

Kit Components

  • RayBio® SARS-CoV-2 spike protein peptide array
  • Blocking Buffer
  • Wash Buffer I
  • Wash Buffer II
  • Biotin-conjugated secondary antibody
  • Cy3 equivalent dye conjugated streptavidin
  • Array accessories (including slide incubation chamber assembly, gasket, adhesive plastic strips, etc.)

Other Materials Required

  • Distilled water
  • Small plastic boxes or containers
  • Orbital shaker or oscillating rocker
  • Pipettors, pipette tips and other common lab consumables
  • Aluminum foil
  • Laser fluorescence scanner

View Compatible Laser Scanners

Don't have a compatible scanner? RayBiotech now offers FREE scanning service for all RayBio glass slide antibody arrays! Learn More

Storage/Stability

Upon receipt, all kit components should be stored at -20 °C to -80 °C until ready to use. Stored properly, the kit will retain complete activity for up to 6 months.
