PD-1 Epitope Mapping Peptide Array
The PD-1 (programmed cell death protein 1/CD279)Â Epitope Mapping Peptide Array is a semi-quantitative array displaying 254 synthesized peptides representing the full-length PD-1. It is suitable for antibody epitope mapping and detection of IgG, IgA, IgM, IgE, etc. in serum, plasma, and many other liquid sample types.
For a service quote, please fill out the Epitope Mapping Array Quote Request Form.
Product Description
Specifications
| Size | 4 Sample Kit, 8 Sample Kit, 16 Sample Kit |
|---|---|
| Species | Human |
| Accession Number | Q15116 |
| Protein Name / Synonyms | PD-1 / programmed cell death protein 1 / CD279 |
| Quantitative/Semi-Quantitative | Semi-Quantitative |
| Number of Targets Detected | 254 |
| Compatible Sample Types | Plasma, Serum, Ascites, Hybridoma cell culture medium, Purified antibodies, Purified protein, DNA Aptamers, Other fluids |
| Solid Support | Glass Slide |
| Method Of Detection | Fluorescence Laser Scanner |
| Research Area | Antibody Drug Development, Drug Antibody (DA) Detection |
| Estimated Lead Time | 4-6 weeks |
| Shipping Type | Blue ice |
| Storage | -20°C |
Amazon Gift Cards!
$5 Amazon gift card in every kit box purchased.
| 1. FLDSPDRPWNPP | 2. LDSPDRPWNPPT | 3. DSPDRPWNPPTF | 4. SPDRPWNPPTFS |
| 5. PDRPWNPPTFSP | 6. DRPWNPPTFSPA | 7. RPWNPPTFSPAL | 8. PWNPPTFSPALL |
| 9. WNPPTFSPALLV | 10. NPPTFSPALLVV | 11. PPTFSPALLVVT | 12. PTFSPALLVVTE |
| 13. TFSPALLVVTEG | 14. FSPALLVVTEGD | 15. SPALLVVTEGDN | 16. PALLVVTEGDNA |
| 17. ALLVVTEGDNAT | 18. LLVVTEGDNATF | 19. LVVTEGDNATFT | 20. VVTEGDNATFTC |
| 21. VTEGDNATFTCS | 22. TEGDNATFTCSF | 23. EGDNATFTCSFS | 24. GDNATFTCSFSN |
| 25. DNATFTCSFSNT | 26. NATFTCSFSNTS | 27. ATFTCSFSNTSE | 28. TFTCSFSNTSES |
| 29. FTCSFSNTSESF | 30. TCSFSNTSESFV | 31. CSFSNTSESFVL | 32. SFSNTSESFVLN |
| 33. FSNTSESFVLNW | 34. SNTSESFVLNWY | 35. NTSESFVLNWYR | 36. TSESFVLNWYRM |
| 37. SESFVLNWYRMS | 38. ESFVLNWYRMSP | 39. SFVLNWYRMSPS | 40. FVLNWYRMSPSN |
| 41. VLNWYRMSPSNQ | 42. LNWYRMSPSNQT | 43. NWYRMSPSNQTD | 44. WYRMSPSNQTDK |
| 45. YRMSPSNQTDKL | 46. RMSPSNQTDKLA | 47. MSPSNQTDKLAA | 48. SPSNQTDKLAAF |
| 49. PSNQTDKLAAFP | 50. SNQTDKLAAFPE | 51. NQTDKLAAFPED | 52. QTDKLAAFPEDR |
| 53. TDKLAAFPEDRS | 54. DKLAAFPEDRSQ | 55. KLAAFPEDRSQP | 56. LAAFPEDRSQPG |
| 57. AAFPEDRSQPGQ | 58. AFPEDRSQPGQD | 59. FPEDRSQPGQDC | 60. PEDRSQPGQDCR |
| 61. EDRSQPGQDCRF | 62. DRSQPGQDCRFR | 63. RSQPGQDCRFRV | 64. SQPGQDCRFRVT |
| 65. QPGQDCRFRVTQ | 66. PGQDCRFRVTQL | 67. GQDCRFRVTQLP | 68. QDCRFRVTQLPN |
| 69. DCRFRVTQLPNG | 70. CRFRVTQLPNGR | 71. RFRVTQLPNGRD | 72. FRVTQLPNGRDF |
| 73. RVTQLPNGRDFH | 74. VTQLPNGRDFHM | 75. TQLPNGRDFHMS | 76. QLPNGRDFHMSV |
| 77. LPNGRDFHMSVV | 78. PNGRDFHMSVVR | 79. NGRDFHMSVVRA | 80. GRDFHMSVVRAR |
| 81. RDFHMSVVRARR | 82. DFHMSVVRARRN | 83. FHMSVVRARRND | 84. HMSVVRARRNDS |
| 85. MSVVRARRNDSG | 86. SVVRARRNDSGT | 87. VVRARRNDSGTY | 88. VRARRNDSGTYL |
| 89. RARRNDSGTYLC | 90. ARRNDSGTYLCG | 91. RRNDSGTYLCGA | 92. RNDSGTYLCGAI |
| 93. NDSGTYLCGAIS | 94. DSGTYLCGAISL | 95. SGTYLCGAISLA | 96. GTYLCGAISLAP |
| 97. TYLCGAISLAPK | 98. YLCGAISLAPKA | 99. LCGAISLAPKAQ | 100. CGAISLAPKAQI |
| 101. GAISLAPKAQIK | 102. AISLAPKAQIKE | 103. ISLAPKAQIKES | 104. SLAPKAQIKESL |
| 105. LAPKAQIKESLR | 106. APKAQIKESLRA | 107. PKAQIKESLRAE | 108. KAQIKESLRAEL |
| 109. AQIKESLRAELR | 110. QIKESLRAELRV | 111. IKESLRAELRVT | 112. KESLRAELRVTE |
| 113. ESLRAELRVTER | 114. SLRAELRVTERR | 115. LRAELRVTERRA | 116. RAELRVTERRAE |
| 117. AELRVTERRAEV | 118. ELRVTERRAEVP | 119. LRVTERRAEVPT | 120. RVTERRAEVPTA |
| 121. VTERRAEVPTAH | 122. TERRAEVPTAHP | 123. ERRAEVPTAHPS | 124. RRAEVPTAHPSP |
| 125. RAEVPTAHPSPS | 126. AEVPTAHPSPSP | 127. EVPTAHPSPSPR | 128. VPTAHPSPSPRP |
| 129. PTAHPSPSPRPA | 130. TAHPSPSPRPAG | 131. AHPSPSPRPAGQ | 132. HPSPSPRPAGQF |
| 133. PSPSPRPAGQFQ | 134. SPSPRPAGQFQT | 135. PSPRPAGQFQTL | 136. SPRPAGQFQTLV |
| 137. PRPAGQFQTLVV | 138. RPAGQFQTLVVG | 139. PAGQFQTLVVGV | 140. AGQFQTLVVGVV |
| 141. GQFQTLVVGVVG | 142. QFQTLVVGVVGG | 143. FQTLVVGVVGGL | 144. QTLVVGVVGGLL |
| 145. TLVVGVVGGLLG | 146. LVVGVVGGLLGS | 147. VVGVVGGLLGSL | 148. VGVVGGLLGSLV |
| 149. GVVGGLLGSLVL | 150. VVGGLLGSLVLL | 151. VGGLLGSLVLLV | 152. GGLLGSLVLLVW |
| 153. GLLGSLVLLVWV | 154. LLGSLVLLVWVL | 155. LGSLVLLVWVLA | 156. GSLVLLVWVLAV |
| 157. SLVLLVWVLAVI | 158. LVLLVWVLAVIC | 159. VLLVWVLAVICS | 160. LLVWVLAVICSR |
| 161. LVWVLAVICSRA | 162. VWVLAVICSRAA | 163. WVLAVICSRAAR | 164. VLAVICSRAARG |
| 165. LAVICSRAARGT | 166. AVICSRAARGTI | 167. VICSRAARGTIG | 168. ICSRAARGTIGA |
| 169. CSRAARGTIGAR | 170. SRAARGTIGARR | 171. RAARGTIGARRT | 172. AARGTIGARRTG |
| 173. ARGTIGARRTGQ | 174. RGTIGARRTGQP | 175. GTIGARRTGQPL | 176. TIGARRTGQPLK |
| 177. IGARRTGQPLKE | 178. GARRTGQPLKED | 179. ARRTGQPLKEDP | 180. RRTGQPLKEDPS |
| 181. RTGQPLKEDPSA | 182. TGQPLKEDPSAV | 183. GQPLKEDPSAVP | 184. QPLKEDPSAVPV |
| 185. PLKEDPSAVPVF | 186. LKEDPSAVPVFS | 187. KEDPSAVPVFSV | 188. EDPSAVPVFSVD |
| 189. DPSAVPVFSVDY | 190. PSAVPVFSVDYG | 191. SAVPVFSVDYGE | 192. AVPVFSVDYGEL |
| 193. VPVFSVDYGELD | 194. PVFSVDYGELDF | 195. VFSVDYGELDFQ | 196. FSVDYGELDFQW |
| 197. SVDYGELDFQWR | 198. VDYGELDFQWRE | 199. DYGELDFQWREK | 200. YGELDFQWREKT |
| 201. GELDFQWREKTP | 202. ELDFQWREKTPE | 203. LDFQWREKTPEP | 204. DFQWREKTPEPP |
| 205. FQWREKTPEPPV | 206. QWREKTPEPPVP | 207. WREKTPEPPVPC | 208. REKTPEPPVPCV |
| 209. EKTPEPPVPCVP | 210. KTPEPPVPCVPE | 211. TPEPPVPCVPEQ | 212. PEPPVPCVPEQT |
| 213. EPPVPCVPEQTE | 214. PPVPCVPEQTEY | 215. PVPCVPEQTEYA | 216. VPCVPEQTEYAT |
| 217. PCVPEQTEYATI | 218. CVPEQTEYATIV | 219. VPEQTEYATIVF | 220. PEQTEYATIVFP |
| 221. EQTEYATIVFPS | 222. QTEYATIVFPSG | 223. TEYATIVFPSGM | 224. EYATIVFPSGMG |
| 225. YATIVFPSGMGT | 226. ATIVFPSGMGTS | 227. TIVFPSGMGTSS | 228. IVFPSGMGTSSP |
| 229. VFPSGMGTSSPA | 230. FPSGMGTSSPAR | 231. PSGMGTSSPARR | 232. SGMGTSSPARRG |
| 233. GMGTSSPARRGS | 234. MGTSSPARRGSA | 235. GTSSPARRGSAD | 236. TSSPARRGSADG |
| 237. SSPARRGSADGP | 238. SPARRGSADGPR | 239. PARRGSADGPRS | 240. ARRGSADGPRSA |
| 241. RRGSADGPRSAQ | 242. RGSADGPRSAQP | 243. GSADGPRSAQPL | 244. SADGPRSAQPLR |
| 245. ADGPRSAQPLRP | 246. DGPRSAQPLRPE | 247. GPRSAQPLRPED | 248. PRSAQPLRPEDG |
| 249. RSAQPLRPEDGH | 250. SAQPLRPEDGHC | 251. AQPLRPEDGHCS | 252. QPLRPEDGHCSW |
| 253. PLRPEDGHCSWP | 254. LRPEDGHCSWPL |
Application Notes
- Identify high antigenicity epitopes for antibody production & vaccine development
- Locate (auto)antigen epitopes of (auto)antibodies
- Define the best antibody clone against the protein-of-interest
- Perform epitope mutant analysis
- Map B cell epitopes
Service Features
- Small serum sample volume required (2 µl)
- High density (simultaneously analyze hundreds of overlapping peptides)
- High sensitivity
- Large dynamic range
- Suitable for high-throughput assays
- High efficiency and accuracy
- Affordable, quick and simple to use
Kit Components
- RayBio® human PD-1 protein peptide array
- Blocking Buffer
- Wash Buffer I
- Wash Buffer II
- Biotin-conjugated secondary antibody
- Cy3 equivalent dye conjugated streptavidin
- Array accessories (including slide incubation chamber assembly, gasket, adhesive plastic strips, etc.)
Other Materials Required
- Distilled water
- Small plastic boxes or containers
- Orbital shaker or oscillating rocker
- Pipettors, pipette tips and other common lab consumables
- Aluminum foil
- Laser fluorescence scanner
View Compatible Laser Scanners
Don't have a compatible scanner? RayBiotech now offers FREE scanning service for all RayBio glass slide antibody arrays! Learn More
Storage/Stability
Upon receipt, all kit components should be stored at -20 °C to -80 °C until ready to use. Stored properly, the kit will retain complete activity for up to 6 months.
