IL-2 Epitope Mapping Peptide Array
The IL-2Â Epitope Mapping Peptide Array is a semi-quantitative array displaying 122 synthesized peptides representing the full-length IL-2. It is suitable for antibody epitope mapping and detection of IgG, IgA, IgM, IgE, etc. in serum, plasma, and many other liquid sample types.
For a service quote, please fill out the Epitope Mapping Array Quote Request Form.
Product Description
Specifications
| Size | 4 Sample Kit, 8 Sample Kit, 16 Sample Kit |
|---|---|
| Species | Human |
| Accession Number | P60568 |
| Protein Name / Synonyms | Interleukin-2 (IL-2) (T-cell growth factor) (TCGF) (Aldesleukin) |
| Quantitative/Semi-Quantitative | Semi-Quantitative |
| Number of Targets Detected | 122 |
| Compatible Sample Types | Plasma, Serum, Ascites, Hybridoma cell culture medium, Purified antibodies, Purified protein, DNA Aptamers, Other fluids |
| Solid Support | Glass Slide |
| Method Of Detection | Fluorescence Laser Scanner |
| Research Area | Antibody Drug Development, Drug Antibody (DA) Detection |
| Estimated Lead Time | 4-6 weeks |
| Shipping Type | Blue ice |
| Storage | -20°C |
Amazon Gift Cards!
$5 Amazon gift card in every kit box purchased.
| 1. APTSSSTKKTQL | 2. PTSSSTKKTQLQ | 3. TSSSTKKTQLQL | 4. SSSTKKTQLQLE |
| 5. SSTKKTQLQLEH | 6. STKKTQLQLEHL | 7. TKKTQLQLEHLL | 8. KKTQLQLEHLLL |
| 9. KTQLQLEHLLLD | 10. TQLQLEHLLLDL | 11. QLQLEHLLLDLQ | 12. LQLEHLLLDLQM |
| 13. QLEHLLLDLQMI | 14. LEHLLLDLQMIL | 15. EHLLLDLQMILN | 16. HLLLDLQMILNG |
| 17. LLLDLQMILNGI | 18. LLDLQMILNGIN | 19. LDLQMILNGINN | 20. DLQMILNGINNY |
| 21. LQMILNGINNYK | 22. QMILNGINNYKN | 23. MILNGINNYKNP | 24. ILNGINNYKNPK |
| 25. LNGINNYKNPKL | 26. NGINNYKNPKLT | 27. GINNYKNPKLTR | 28. INNYKNPKLTRM |
| 29. NNYKNPKLTRML | 30. NYKNPKLTRMLT | 31. YKNPKLTRMLTF | 32. KNPKLTRMLTFK |
| 33. NPKLTRMLTFKF | 34. PKLTRMLTFKFY | 35. KLTRMLTFKFYM | 36. LTRMLTFKFYMP |
| 37. TRMLTFKFYMPK | 38. RMLTFKFYMPKK | 39. MLTFKFYMPKKA | 40. LTFKFYMPKKAT |
| 41. TFKFYMPKKATE | 42. FKFYMPKKATEL | 43. KFYMPKKATELK | 44. FYMPKKATELKH |
| 45. YMPKKATELKHL | 46. MPKKATELKHLQ | 47. PKKATELKHLQC | 48. KKATELKHLQCL |
| 49. KATELKHLQCLE | 50. ATELKHLQCLEE | 51. TELKHLQCLEEE | 52. ELKHLQCLEEEL |
| 53. LKHLQCLEEELK | 54. KHLQCLEEELKP | 55. HLQCLEEELKPL | 56. LQCLEEELKPLE |
| 57. QCLEEELKPLEE | 58. CLEEELKPLEEV | 59. LEEELKPLEEVL | 60. EEELKPLEEVLN |
| 61. EELKPLEEVLNL | 62. ELKPLEEVLNLA | 63. LKPLEEVLNLAQ | 64. KPLEEVLNLAQS |
| 65. PLEEVLNLAQSK | 66. LEEVLNLAQSKN | 67. EEVLNLAQSKNF | 68. EVLNLAQSKNFH |
| 69. VLNLAQSKNFHL | 70. LNLAQSKNFHLR | 71. NLAQSKNFHLRP | 72. LAQSKNFHLRPR |
| 73. AQSKNFHLRPRD | 74. QSKNFHLRPRDL | 75. SKNFHLRPRDLI | 76. KNFHLRPRDLIS |
| 77. NFHLRPRDLISN | 78. FHLRPRDLISNI | 79. HLRPRDLISNIN | 80. LRPRDLISNINV |
| 81. RPRDLISNINVI | 82. PRDLISNINVIV | 83. RDLISNINVIVL | 84. DLISNINVIVLE |
| 85. LISNINVIVLEL | 86. ISNINVIVLELK | 87. SNINVIVLELKG | 88. NINVIVLELKGS |
| 89. INVIVLELKGSE | 90. NVIVLELKGSET | 91. VIVLELKGSETT | 92. IVLELKGSETTF |
| 93. VLELKGSETTFM | 94. LELKGSETTFMC | 95. ELKGSETTFMCE | 96. LKGSETTFMCEY |
| 97. KGSETTFMCEYA | 98. GSETTFMCEYAD | 99. SETTFMCEYADE | 100. ETTFMCEYADET |
| 101. TTFMCEYADETA | 102. TFMCEYADETAT | 103. FMCEYADETATI | 104. MCEYADETATIV |
| 105. CEYADETATIVE | 106. EYADETATIVEF | 107. YADETATIVEFL | 108. ADETATIVEFLN |
| 109. DETATIVEFLNR | 110. ETATIVEFLNRW | 111. TATIVEFLNRWI | 112. ATIVEFLNRWIT |
| 113. TIVEFLNRWITF | 114. IVEFLNRWITFC | 115. VEFLNRWITFCQ | 116. EFLNRWITFCQS |
| 117. FLNRWITFCQSI | 118. LNRWITFCQSII | 119. NRWITFCQSIIS | 120. RWITFCQSIIST |
| 121. WITFCQSIISTL | 122. ITFCQSIISTLT | Â | Â |
Application Notes
- Identify high antigenicity epitopes for antibody production & vaccine development
- Locate (auto)antigen epitopes of (auto)antibodies
- Define the best antibody clone against the protein-of-interest
- Perform epitope mutant analysis
- Map B cell epitopes
Service Features
- Small serum sample volume required (2 µl)
- High density (simultaneously analyze hundreds of overlapping peptides)
- High sensitivity
- Large dynamic range
- Suitable for high-throughput assays
- High efficiency and accuracy
- Affordable, quick and simple to use
Kit Components
- RayBio® human IL-2 protein peptide array
- Blocking Buffer
- Wash Buffer I
- Wash Buffer II
- Biotin-conjugated secondary antibody
- Cy3 equivalent dye conjugated streptavidin
- Array accessories (including slide incubation chamber assembly, gasket, adhesive plastic strips, etc.)
Other Materials Required
- Distilled water
- Small plastic boxes or containers
- Orbital shaker or oscillating rocker
- Pipettors, pipette tips and other common lab consumables
- Aluminum foil
- Laser fluorescence scanner
View Compatible Laser Scanners
Don't have a compatible scanner? RayBiotech now offers FREE scanning service for all RayBio glass slide antibody arrays! Learn More
Storage/Stability
Upon receipt, all kit components should be stored at -20 °C to -80 °C until ready to use. Stored properly, the kit will retain complete activity for up to 6 months.
