Human IL-6 Immuno-PCR Assay Kit, BIQ-ELISA™

The Human Bead-based Immuno-Quantitative (BIQ) IL-6 ELISA Kit merges the specificity of sandwich-based ELISA, the sensitivity of real-time PCR, and the easy manipulation of microspheres to detect even the lowest levels of IL-6 in serum, plasma, and cell culture supernatant samples.

As low as $639.00
In stock
Only %1 left
Catalog #:
BIQH-IL6
-
+

Product Description

Specifications

Size 1 Plate Kit, 2 Plate Kit, 5 Plate Kit
Species Human
Host Species Human
Accession Number P05231
Gene Id 3569
Gene Symbols IL6, IFNB2
Protein Name / Synonyms Interleukin-6 (IL-6) (B-cell stimulatory factor 2) (BSF-2) (CTL differentiation factor) (CDF) (Hybridoma growth factor) (Interferon beta-2) (IFN-beta-2)
Quantitative/Semi-Quantitative Quantitative
Specificity The IL-6 antibodies used in the kit are specific to human IL-6.
Compatible Sample Types Cell Culture Supernatants, Plasma, Serum
Solid Support 96-well Microplate
Method Of Detection qPCR
Design Principle Sandwich-based
Sensitivity 0.03 pg/ml
Detection Range 0.27 pg/ml - 200 pg/ml
Estimated Lead Time 3-5 business days
Shipping Type Blue ice
Storage -20°C

Risk-Free Guarantee

We offer a 100% guarantee on all ELISA kits and membrane cytokine arrays.

Learn More
Amazon Gift Cards!

$5 Amazon gift card in every kit box purchased.

Introduction

The RayBio® Bead-based Immuno Quantitative Enzyme Linked ImumunoSorbent Assay (BIQ-ELISA) is an innovative protein detection method that merges the specificity of sandwich-based ELISA, the sensitivity of real-time PCR, and the easy manipulation of magnetic microspheres. In this system, the capture antibody (CAB) is biotin-labelled and pre-absorbed onto streptavidin-coated beads (CAB-Biotin-SA-Beads), while the detection antibody (DAB) is conjugated with a unique oligonucleotide acid (ONA) barcode for signal amplification (DAB-ONA).

The procedure is straightforward and a total of four hours is required to complete the assay. Part 1: The formation and purification of the immunocomplex (ONA-DAB-Antigen-CAB-Biotin-SA-Beads). Samples are incubated with DAB-ONA and CAB-Biotin-SA-Beads in a supplied 96-well plate. In the presence of the target protein, the DAB-ONA binds to the target and attaches to the CAB-Biotin-SA-Beads via the biotin-streptavidin interaction and the unbound proteins are removed through washing with a magnetic automated washer. Part 2: PCR amplification. The bound immunocomplex will be released from the beads and transferred as the template for qPCR. Primers and PCR master mix are added to the wells and data will be collected using qPCR. Ct values obtained from the qPCR are then used to calculate the amount of antigen contained in each sample, where lower Ct values indicate a higher concentration of antigen. In a real experiment, a set of target protein standards with known concentrations will be run simultaneously to generate a standard curve for quantifying unknown samples.

The RayBio® BIQ-ELISA technology represents a significant advancement in protein detection assays, providing an ultrasensitive and highly specific method for quantifying proteins in biological samples. This technology's ability to combine multiple advantages of existing methods into a single, easy-to-use platform makes it a powerful tool for research community. The RayBio® BIQ-ELISA kits can be used for the quantitative measurement of proteins in various sample types including serum, plasma, and cell culture supernatants with femtogram per milliliter detection sensitivity.

Product Features

  • Ultra-sensitivity: Up to 1,000x more sensitive than traditional ELISA
  • Ultra-low sample volume: Less than 10 µL needed
  • Specificity: Sandwich-based detection
  • Simplicity: Two steps processing
  • Efficiency: Get data within 4 hours
  • Multiplexing ready*

*Increase your throughput with RayBiotech's customizable multiplex bead-based immuno-PCR kits, designed for panels of up to 5 targets. This platform helps you save time, reduce costs, and decrease sample consumption by >2000% compared to traditional colorimetric ELISA. For more details, reach out to us at techsupport@raybiotech.com.

Standard Curve

Standard Curve

Kit Components

ComponentSize / Qty
96-well V-bottom Plate1 plate
96-well Plate Film1 plate
96-well PCR Plate*1 plate
1X Assay Diluent1 bottle (25 mL)
20X Wash Buffer Concentrate1 bottle (30 mL)
Human IL-6 Standard1 vial
Human IL-6 Antibody Coated Beads1 vial (0.6 mL)
Oligonucleotide Conjugated Antibody1 vial (10 μL)
1X Elution Buffer1 vial (5 mL)
2X PCR Master Mix1 vial (1.05 mL)
Primer Mix1 vial (lyophilized)
PCR Plate Film1 piece

*The PCR plate used is a 0.2 mL, non-skirted 96-well plate (Thermo Fisher, cat. no. AB0600). Please ensure compatibility with your PCR machine prior to purchase. For additional information contact technical support (techsupport@raybiotech.com).

Additional Materials Required

  • Real-time PCR instrument, Bio-Rad or QuantStudio™ recommended
  • Orbital 96-well plate shaker (with ability to reach 700 rpm)
  • Microplate Washer (BioTek 405 TS Washer recommended) and a compatible 96-well V-bottom plate magnetic stand (ThermoFisher AM10050 recommended)
  • Precision pipettes to deliver 1 μL to 1 mL volumes
  • Pipette tips (barrier tips are recommended to reduce contamination)
  • Adjustable 1-25 mL pipettes for reagent preparation
  • Centrifuge that can spin 96 well plates at 500 g
  • Nuclease-free water or deionized water
  • 1.5 mL, 2 mL, or 5 mL microcentrifuge tubes

Assay Procedure Summary

  1. Prepare all reagents, samples and standards as instructed.
  2. Add 5 μL of the bead and conjugate mix, and 5 μL of each standard and sample to each well. Incubate for 2.5 hours at room temperature while shaking.
  3. Add 40 μL Assay Diluent and wash the plate using a Microplate Washer.
  4. Add 40 μL Elution buffer to each well. Incubate for 10 minutes at room temperature.
  5. Prepare PCR/Primer Master Mix and pipette 15 μL into each well of the PCR plate.
  6. Transfer 5 μL supernatant from V-bottom plate to the PCR plate.
  7. Run real-time PCR.

Storage/Stability

Upon receiving the kit, store 2X PCR Master Mix, Primer Mix and Human IL-6 Standard at -20°C. Store other components at 4°C. If stored at the proper temperature, the kit may be stored for up to 12 months from the date of shipment. Avoid repeated freeze-thaw cycles.
